Περιγραφή
Processor
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen(TM) 8000 Series, AMD Ryzen 9000 Series, AMD Ryzen 7000 Series
Processor socket: Socket AM5
Graphics
Graphics card family: AMD
On-board graphics card: Yes
Graphics card: AMD RDNA 2
Features
Windows operating systems supported: Windows 11, Windows 10
Audio output channels: 7.1 channels
Motherboard chipset: AMD A620
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Memory
Memory channels: Dual-channel
Memory slots type: DIMM
Number of memory slots: 4
Maximum internal memory: 256 GB
Supported memory types: DDR5 UDIMM
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Ethernet LAN: Yes
Wi-Fi: No
LAN controller: Dragon RTL8125BG
Ethernet interface type: Gigabit Ethernet
Bluetooth: No
Internal I/O
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
TPM connector: Yes
CPU fan connector: Yes
Power fan connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 2.0 connectors: 2
Number of SATA III connectors: 2
BIOS
BIOS type: UEFI AMI
Storage controllers
RAID levels: 10, 1, 0
Number of HDDs supported: 2
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (E) slots: 1
Number of M.2 (M) slots: 3
PCI Express x4 (Gen 3.x) slots: 1
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage.
Warranty: warranty 36 months
