Περιγραφή
CPU Support: Supports AMD AM4 Socket Ryzen™ 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors
Chipset: AMD B550
MB Size: microATX
Memory:4 DIMM DDR4 Sockets for ECC & non-ECC un-buffered DDR4 RAM up to 3200MHz or up to 4733+MHz (OC). Max 128GB. Dual Channel architecture
VGA: Supported only with CPUs with integrated AMD Radeon Vega Series Graphics (Ryzen 3 2200G, Ryzen 5 2400G,...)
VGA Out: 1x D-SUB (max.res up to 1920x1200 @60Hz), 1x Display Port(max.res up to5K @120Hz), 1x HDMI v2.1 (max.res up to 4K @60Hz). Support DirectX 12
Slots: For AMD Ryzen series CPUs supports 2x PCIe (x16) v4.0, for AMD Ryzen series APUS 2x PCIe (x16) v3.0, 2x PCIe (x8) v3.0. 1x PCIe (x1) v3.0, 1x 1x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
Storage: 6x SATA3 6Gbps ports support RAID 0/1/10, 1x Hyper M.2, supports M Key type 2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (with Vermeer, Matisse) or Gen3x4 (32 Gb/s) (with Cezanne, Renoir and Picasso), 1x M.2 Socket, supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x2 (16 Gb/s). Supports NVMe SSD as boot disks
NIC: Gigabit Ethernet LAN 10/100/1000 Mbps
Audio: 7.1 Channel HD Audio. Supports Surge Protection, Nahimic Audio
I/O: 1x PS/2 Mouse/Keyboard port, 1x D-Sub, 1x HDMI, 1x Display Port, 2(+4int) USB 2.0, 4(+4int) USB 3.2 Gen1 type-A, 1x USB 3.2 Gen2 Type-A (10 Gb/s), 1x USB 3.2 Gen2 Type-C,1x RJ45 (LAN), 3 Audio jacks. 1x Antenna Bracket, 1x Front Panel Audio Connector
Εγγύηση: 2 χρόνια
