Περιγραφή
Processor
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Features
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel B860
Motherboard chipset family: Intel
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Audio chip: Realtek ALC897
Memory
Memory slots type: DIMM
Number of memory slots: 4
Supported memory types: DDR5-SDRAM
Unbuffered memory: Yes
Maximum internal memory: 256 GB
Memory channels: Dual-channel
Weight & dimensions
Depth: 244 mm
Width: 244 mm
Network
Ethernet interface type: 2.5 Gigabit Ethernet
Ethernet LAN: Yes
Wi-Fi: No
LAN controller: Dragon RTL8125BG
Internal I/O
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 4
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
Front panel audio connector: Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of SATA III connectors: 4
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
USB 2.0 connectors: 2
TPM connector: Yes
EPS power connector (8-pin): Yes
BIOS
BIOS type: EFI AMI
Packaging content
Cables included: SATA
Storage controllers
RAID levels: 1, 10, 0, 5
Number of storage drives supported: 7
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Rear panel I/O ports
USB 3.2 Gen 2x2 Type-C ports quantity: 1
Line-in: Yes
Microphone in: Yes
DisplayPorts quantity: 1
Ethernet LAN (RJ-45) ports: 1
DisplayPort version: 1.4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 2.0 ports quantity: 2
HDMI ports quantity: 2
Expansion slots
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x4 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 1
Safety warning
Warnings: In case of installation problems, contact a qualified service technician., Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics.
Warranty: warranty 36 months
