Περιγραφή
Processor
Processor socket: LGA 1851 (Socket V1)
Processor manufacturer: Intel
Graphics
Graphics card family: Intel
On-board graphics card: Yes
Features
Motherboard chipset: Intel B860
Motherboard form factor: micro ATX
Windows operating systems supported: Windows 11 x64
Audio output channels: 7.1 channels
Audio chip: Realtek ALC1220
Motherboard chipset family: Intel
Memory
ECC ?ompatibility: Non-ECC
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Memory slots type: DIMM
Memory channels: Dual-channel
Number of memory slots: 4
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11g
Bluetooth version: 5.3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth: Yes
Ethernet LAN: Yes
LAN controller: Dragon RTL8125BG
Wi-Fi: Yes
Internal I/O
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 5
Number of EPS power connectors (8-pin): 2
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
Number of chassis fan connectors: 3
CPU fan connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
EPS power connector (8-pin): Yes
TPM connector: Yes
Number of SATA III connectors: 4
RGB LED pin header: Yes
USB 2.0 connectors: 2
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Storage controllers
RAID levels: 1, 0, 10, 5
Supported storage drive interfaces: M.2, SATA III
RAID support: Yes
Rear panel I/O ports
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 6
Microphone in: Yes
S/PDIF out port: Yes
HDMI ports quantity: 1
Thunderbolt ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
Expansion slots
PCI Express x4 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
Number of M.2 (M) slots: 1
Safety warning
Warnings: Do not open or modify the motherboard to prevent damage., When disposing of the product, follow local regulations for the recycling of electronics., In case of installation problems, contact a qualified service technician.
Warranty: warranty 36 months
