Processor
Processor manufacturer: Intel
Supported processor sockets: LGA 1851
Compatible processor series: Intel Core Ultra (Series 2)
Processor socket: LGA 1851 (Socket V1)
Graphics
HDCP: Yes
Maximum resolution: 7680 x 4320 pixels
Parallel processing technology support: Not supported
Features
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64
Motherboard chipset: Intel B860
Audio chip: Realtek ALC1220
Product colour: White
Memory
Memory channels: Dual-channel
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Number of memory slots: 4
ECC ?ompatibility: Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Wi-Fi standards: Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11b, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), 802.11g
Bluetooth: Yes
Wi-Fi: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Bluetooth version: 5.3
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Dragon RTL8125BG
Internal I/O
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
TPM connector: Yes
USB 2.0 connectors: 2
Number of chassis fan connectors: 5
12V power connector: Yes
RGB LED pin header: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of water pump connectors: 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of EPS power connectors (8-pin): 2
USB 3.2 Gen 2x2 connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID levels: 1, 5, 10, 0
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Number of storage drives supported: 8
Rear panel I/O ports
USB connector type: USB Type-C, USB Type-A
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Headphone outputs: 1
S/PDIF out port: Yes
WiFi-AP antenna jack: 2
Thunderbolt ports quantity: 1
DisplayPort version: 1.4
DisplayPorts quantity: 1
Microphone in: Yes
HDMI version: 2.1
HDMI ports quantity: 1
USB 2.0 ports quantity: 3
Expansion slots
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
3rd M.2 highest PCI Express generation: 4.0
4th M.2 highest PCI Express generation: 4.0
4th M.2 largest key size: 2280
Safety warning
Warnings: When disposing of the product, follow local regulations for the recycling of electronics., Do not open or modify the motherboard to prevent damage., In case of installation problems, contact a qualified service technician.
Warranty: warranty 36 months
