Processor
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
Processor socket: Socket AM5
Graphics
HDCP: Yes
Maximum resolution: 3840 x 2160 pixels
Parallel processing technology support: Not supported
Features
Motherboard chipset: AMD B850
Motherboard chipset family: AMD
Product colour: Black
Audio chip: Realtek ALC897
Motherboard form factor: micro ATX
Audio output channels: 7.1 channels
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory
Maximum internal memory: 128 GB
ECC ?ompatibility: ECC & Non-ECC
Memory channels: Dual-channel
Number of memory slots: 2
Memory slots type: DIMM
Supported memory types: DDR5-SDRAM
Weight & dimensions
Width: 244 mm
Depth: 226 mm
Network
LAN controller: Dragon RTL8125BG
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
Mobile network connection: No
Wi-Fi: No
Internal I/O
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Number of SATA III connectors: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Front panel audio connector: Yes
USB 2.0 connectors: 2
Number of CPU fan connectors: 2
EPS power connector (8-pin): Yes
TPM connector: Yes
RGB LED pin header: Yes
Number of chassis fan connectors: 3
USB Type-C ports quantity: 1
12V power connector: Yes
Number of RGB LED pin headers: 1
Number of EPS power connectors (8-pin): 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Screws included: Yes
Storage controllers
RAID levels: 0, 1, 10
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID support: Yes
Supported storage drive types: HDD & SSD
Rear panel I/O ports
DisplayPorts quantity: 1
DisplayPort version: 1.4
USB 2.0 ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
Audio output: 3.5 mm
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Microphone in: Yes
HDMI version: 2.1
Line-in: Yes
Expansion slots
Number of M.2 (M) slots: 2
Number of M.2 (E) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
PCI Express x1 (Gen 4.x) slots: 1
PCI Express x16 (Gen 5.x) slots: 1
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
Safety warning
Warnings: Dispose of in accordance with local regulations for electronic waste., Avoid contact with liquids to prevent electronic damage., Do not disassemble to avoid damage to internal components and loss of warranty.
Warranty: warranty 36 months
