Περιγραφή
Processor
Processor manufacturer: AMD
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Processor socket: Socket AM5
Graphics
Maximum resolution: 3840 x 2160 pixels
HDCP: Yes
Parallel processing technology support: Not supported
Features
Audio output channels: 7.1 channels
Motherboard chipset family: AMD
Product colour: Black
Motherboard chipset: AMD B850
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Audio chip: Realtek ALC897
Memory
Memory channels: Dual-channel
Maximum internal memory: 256 GB
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Number of memory slots: 4
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Width: 244 mm
Depth: 244 mm
Network
Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), 802.11b, Wi-Fi 6E (802.11ax), 802.11g
Ethernet LAN: Yes
LAN controller: Dragon RTL8125BG
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth: Yes
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi: Yes
Bluetooth version: 5.2
Internal I/O
CPU fan connector: Yes
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
EPS power connector (8-pin): Yes
Number of SATA III connectors: 4
TPM connector: Yes
Number of chassis fan connectors: 3
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
USB 2.0 connectors: 2
12V power connector: Yes
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
RGB LED pin header: Yes
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID support: Yes
RAID levels: 1, 0, 10
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Number of storage drives supported: 7
Supported storage drive types: HDD & SSD
Rear panel I/O ports
HDMI ports quantity: 1
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 4
DisplayPorts quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB connector type: USB Type-C, USB Type-A
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
DisplayPort version: 1.4
HDMI version: 2.1
Microphone in: Yes
Headphone outputs: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Line-in: Yes
WiFi-AP antenna jack: 2
Expansion slots
Number of M.2 (M) slots: 3
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
PCI Express x4 (Gen 4.x) slots: 1
3rd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
3rd M.2 largest key size: 2280
1st M.2 highest PCI Express generation: 5.0
Safety warning
Warnings: Do not disassemble to avoid damage to internal components and loss of warranty., Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste.
Warranty: warranty 36 months
