Περιγραφή
Processor
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
Processor manufacturer: AMD
Processor socket: Socket AM5
Graphics
HDCP: Yes
Parallel processing technology support: Not supported
Maximum resolution: 3840 x 2160 pixels
Features
Motherboard chipset: AMD B850
Motherboard form factor: ATX
Audio output channels: 7.1 channels
Product colour: White
Windows operating systems supported: Windows 11 x64, Windows 10 x64
Motherboard chipset family: AMD
Audio chip: Realtek ALC4082
Memory
Maximum internal memory: 256 GB
Supported memory types: DDR5-SDRAM
Memory slots type: DIMM
Memory channels: Dual-channel
Unbuffered memory: Yes
Number of memory slots: 4
ECC ?ompatibility: ECC & Non-ECC
Weight & dimensions
Width: 305 mm
Depth: 244 mm
Network
Bluetooth version: 5.4
Wi-Fi: Yes
Wi-Fi standards: Wi-Fi 6E (802.11ax), Wi-Fi 4 (802.11n), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be)
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Dragon RTL8125BG
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Bluetooth: Yes
Internal I/O
ATX Power connector (24-pin): Yes
Front panel audio connector: Yes
12V power connector: Yes
EPS power connector (8-pin): Yes
Number of EPS power connectors (8-pin): 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 2.0 connectors: 2
RGB LED pin header: Yes
Number of CPU fan connectors: 2
Number of RGB LED pin headers: 1
Number of SATA III connectors: 4
TPM connector: Yes
Number of chassis fan connectors: 3
CPU fan connector: Yes
USB 3.2 Gen 2x2 connectors: 1
BIOS
BIOS type: UEFI AMI
Packaging content
Cables included: SATA
Antenna included: Yes
Storage controllers
RAID support: Yes
Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 1, 10, 0
Supported storage drive types: HDD & SSD
Number of storage drives supported: 8
Rear panel I/O ports
Headphone outputs: 2
S/PDIF out port: Yes
WiFi-AP antenna jack: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
USB connector type: USB Type-C, USB Type-A
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
HDMI version: 2.1
Microphone in: Yes
Line-in: Yes
Expansion slots
3rd M.2 highest PCI Express generation: 4.0
1st M.2 highest PCI Express generation: 5.0
3rd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 5.x) slots: 1
2nd M.2 largest key size: 2280
1st M.2 largest key size: 2280
4th M.2 largest key size: 2280
PCI Express x16 (Gen 4.x) slots: 1
4th M.2 highest PCI Express generation: 4.0
Number of M.2 (M) slots: 4
Safety warning
Warnings: Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty.
Warranty: warranty 36 months
